All ssential castings are made of high grade meechanite cast iiron that is stress relieved through annealing to eliminate internal stress.

With the greatest stiffness and stability of the castings, this machine is established to ensure safe operations.

The interlock between electrical cabnet door and power supply is established to ensure safe opration.

The spring loaded type table travel stops will dampen the over travel caused by abnormal opreations.

Saddle travels on Turcite-B coated and hand scraped double V guideways.

Condition	Used
Capacity	457 mm 18.0″ Grinding length
Grinding width	152 mm 6.0″
Distance table to centerline of wheel	450 mm 17.7″
Max. table load	210 kg 462 lbs.
Table	150 x 460 mm 5.9″ x 18.1″ Table size
Max. table travel – manual	482 mm 19.0″
Traverse movement (z)	180 mm 7.1″ Max. manual travel
Spindle	60 Hz 3,450 rpm / 50 Hz 2,850 rpm Spindle speed
Spindle motor	1.5 kW 2 HP
Wheel dimension	Ø 205 × 12.7 × Ø31.75 mm Ø 8” × 0.5” × Ø 1.3” OD x Width x Bore
Machine dimensions	1,900 x 1,400 x 2,130 mm 74.8″ x 55.1″ x 83.9″ Floor space (W x D x H)
Net weight	674 kg 1,480 lbs.
