DURMA MODEL PBH 60 PROFILE BENDING MACHINE

DURMA MODEL PBH 60 PROFILE BENDING MACHINE

or
Call (604) 472-1444

Description

FEATURES:

  • Robust machine frame is manufactured with rugged steel construction and machined after welding for rigidity
  • Large shaft diameters and bearings result in precise bending and also minimize deflection
  • A strong frame and world class components provide a long machine life
  • High drive torque and speed produce short cycle times
  • Minimized straight edge by hydraulic adjustments
  • Low energy and maintenance costs because of friction free planetary swing guides
  • Powerful guide rolls
  • Variable Speed
  • Tie Bar Assembly
  • Digital Readout (X, Y Axis)
  • All Rolls Driven by Planetary Gear Box and Hydramotor
  • 1 Set Standard Hardened and Ground Rolls made of special steel
  • 3 Axis Side Supports
  • Side supports are suitable for angle iron bending
  • 3 axis side supports, front-back, up-down, left-right manual adjustment
  • Movable Command Panel Separate from Machine
  • Horizontal Working Feature
  • Stress-Relieved Steel Construction Body
  • Electrical and Hydraulic Protection Against Overload

    • PBH 60

    Shaft Diameters:

  • Top 2.364″
  • Planetary (2) 2.364″
  • Roll Diameters 7″
  • Motor Power 3 + 2 HP, 220V, 3PH
  • Turning Speed 17 FPM
  • Dimensions 46″ L x 39″ W x 46″ H
  • Weight 2,627 lbs
    • Show All

    Specifications

    ManufacturerDurma
    ConditionNew
